** It is recommended to add 18" to landing space dimensions for safe ascent or descent of the stairway
| MODEL # | ROUGH OPENING | CEILING HEIGHT | PROJECTION (A) | LANDING (B) | DUTY RATING |
| 6P224882 | 22-1/2" X 48" | 8'2" | 67" | 55" | 375lbs |
| 6P225489 | 22-1/2" X 54" | 8'9" | 69" | 59" | 375lbs |
| 6P2254 | 22-1/2" X 54" | 7'6"-10'4" | 79" | 67" | 375lbs |
| 6P254882 | 25-1/2" X 48" | 8'2" | 67" | 55" | 375lbs |
| 6P255489 | 25-1/2" X 54" | 8'9" | 69" | 59" | 375lbs |
| 6P2554 | 25-1/2" X 54" | 7'6"-10'4" | 79" | 67" | 375lbs |
| 6P305489 | 30" X 54" | 8'9" | 69" | 59" | 375lbs |
| 6P3054 | 30" X 54" | 7'6"-10'4" | 79" | 67" | 375lbs |
| 6P306089 | 30" X 60" | 8'9" | 71" | 59" | 375lbs |
| 6P306010 | 30" X 60" | 10'0" | 79" | 67" | 375lbs |
| 6P2260109 | 22-1/2" X 60" | 10'9" | 83" | 71" | 375lbs |
| 6P2560109 | 25-1/2" X 60" | 10'9" | 83" | 71" | 375lbs |
| 6P3060109 | 30" X 60" | 10'9" | 83" | 71" | 375lbs |
American Stairways offers many sizes, duty ratings, energy saving, and code compliant options to meet your requirements. Take a look to see which model works best for you.
