** It is recommended to add 18" to landing space dimensions for safe ascent or descent of the stairway.
| MODEL # | ROUGH OPENING | CEILING HEIGHT | PROJECTION (A) | LANDING (B) | DUTY RATING |
| 4224882 | 22-1/2" X 48" | 8'2" | 65" | 54" | 350lbs |
| 4225489 | 22-1/2" X 54" | 8'9" | 67" | 58" | 350lbs |
| 42254 | 22-1/2" X 54" | 7'6"-10'4" | 77" | 66" | 350lbs |
| 4254882 | 25-1/2" X 48" | 8'2" | 65" | 54" | 350lbs |
| 4255489 | 25-1/2" X 54" | 8'9" | 67" | 58" | 350lbs |
| 42554 | 25-1/2" X 54" | 7'6"-10'4" | 77" | 66" | 350lbs |
American Stairways offers many sizes, duty ratings, energy saving, and code compliant options to meet your requirements. Take a look to see which model works best for you.
